No. | Equipment | Brand & manufactory | Type | Qty. | BestTolerance | PurchaseDate | Comment |
---|---|---|---|---|---|---|---|
1 | NC Lathe | JSWAY/China | #36 | 50 | 0.005mm | 2015-07~2019-02 | RPM6000 |
2 | NC Lathe & Mill | JSWAY/China | #46 | 8 | 0.005mm | 2019-02 | 12-station (4+4 powered-axle ) |
3 | NC Lathe | Santes/China | #45 | 1 | 0.005mm | 2017-03 | 4+4 powered-axle, RPM6000 |
4 | NC Lathe | Tsugami/Japan | BO205 | 15 | 0.005mm | 2015-08~2019-03 | 5-axle (Part Max. diameter 20mm),RPM10000 |
5 | NC Lathe | Tsugami/Japan | BO206 | 1 | 0.005mm | 2017-04 | 6-axle (Part Max. diameter 20mm),RPM10000 |
6 | NC Lathe | Star/Japan | 205RG | 6 | 0.005mm | 2019-03 | 5-axle (Part Max. diameter 23mm),RPM10000 |
7 | CNC Center | Brother/Japan | S500Z1 (14sets tool) | 18 | 0.005mm | 2017-06 | With 18 sets Japan 5-axle rotary table, Max Range500x400x300, RPM16000 |
8 | CNC Center | Brother/Japan | S500Z1 (14sets tool) | 24 | 0.005mm | 2018-06 | With 12 sets Japan 4-axle rotary table, Max Range 500x400x300, RPM16000 |
9 | CNC Center | Brother/Japan | S500Z1 (14sets tool) | 14 | 0.005mm | 2018-03 | With 14 sets Japan 5-axle rotary table, Max Range500x400x300, RPM16000 |
10 | Gear Hobbing Machine | Mitor/China | N120 | 4 | DIN 4 | 2016-06 | 7-axis hobbing machine |
11 | Gear Hobbing Machine | Yunil/Korea | HERA-30 | 4 | DIN 4 | 2016-06 | 8-axis hobbing machine |
12 | Laser etching Machine | Chongtian/China | 1 | 0.01mm | 2018-03 | 20w, can laser etch black/white/gray | |
13 | Gear tester | TTI/Japan | TTI-300H | 1 | 0.001 | 2016-06 | Range: m0.2-12 |
14 | Gear mesh meter | TTI/Japan | TF-40NC | 1 | 0.001 | 2016-06 | Range: m0.15-2 |
15 | 2.5D Projector | Wangming/China | #300 | 2 | 0.004mm | 2018-06 | Max Range 300x200mm |
16 | 3D Projector | Hexagon | Inspector Classic | 1 | 0.002mm | 2018-11 | Max Range 600x800x600mm |
17 | Ultra-sonic cleaner | Jiemeng/China | JP-360ST | 2 | (1800W) | 2017-08 | Heating power: 4.5kw |
Receiving case | → | Design Review | → | Product & process design | → | Making samples | → | Inspection and packing |
Fixture design | ||||||||
↓ | ||||||||
Close | ← | Document Filing | ← | Follow up the result | ← | Send samples for customer confirmation | ← | Data record |
